HIGH RESOLUTION HP TIJ & EPSON PIEZO COMPLIANT DIGITAL PACKAGING PRINTING INKS
Offerings
- Printer & application-specific inks compliant with thermal TIJ DOD & piezoelectric DOD print, high speed, high performance, and high resolution technologies.
- Inks manufactured for printer and industrial grade print head manufacturers - with reliable jetting, adhesion, durability & colour performance.
- Inks for small/large character high resolution piezo secondary coding of corrugated cardboard, trays & rigid plastics, etc.
- Inks for long decap and fast- & ultrafast - dry times, suitable for piezoelectric & thermal TIJ printheads for primary & secondary marking and case coding of flexible packaging, paper, etc.
- Energy-efficient regular aqueous and UV curable (UV light, UV LED) inks for permeable and non-permeable materials (paper, PET, OPP, BOPP, etc.).
- Security packaging inks: UV curable & aqueous UV & IR fluorescent. Visible only under UV or IR light, as applicable. Not visible to the naked eye alone
NO MESS, BOLD, LEGIBLE, AND FULLY FORMED CHARACTERS
Substrates
High resolution prints (up to 600/1200dpi for piezo printheads, and up to 600/2400dpi for TIJ 2.5/TIJ4.0 systems
at speeds of up to 400m/min) on porous, semi-porous and non-porous rigid & flexible heat sensitive materials, including:
- Paper (coated & uncoated): including laminated paper board, coated chip board, corrugated carton papers (for case and inner boxes for eggs, drinks, water bottles, pharmaceuticals, nutritional candy products, fish, cereals, pastas, other foods & beverages, cosmetics/personal care, etc )
- Rigid plastics & Synthetic: PVC/Polycarbonate/Teslin - card; Polyethylene (HDPE) - grocery & other retail packaging bags/containers
- Flexible plastics: acrylic coated blister foil, polypropylene (pp), polyethylene (LDPE) shrink and other packaging films for bagging, casing, wrapping, etc
Applications & Printer/System/Platform Manufacturers
- In-line and off-line packaging (product & secondary case coding). Directly imprinting high definition product authentication, personalisations and other variable data (e.g., best-before dates, serial/batch numbers, quality assurance info., graphics, time format, shift codes, tracking/tracing barcodes and alphanumeric codes, company logos, etc) in small & large font codes/characters (12.7mm, 17mm, 53mm, 70mm high plus) on case, pouch & inner carton.
- Security ID Cards (PC & PVC), Tickets, Lottery Coupons, and other business forms
- Security packaging, invisible marking, & brand protection. Anti-counterfeit, unique markings to protect, verify and authenticate your package/product/identity. Covert text/images/features/control codes can be applied anywhere on the packaging material (and in as many sections as you require to define the complexity of your security) without altering the beauty of your design artwork. Make the Original distinguishable from the Counterfeit!
- Printer/System/Press/Platform: Epson, HP, Canon, Ricoh, Brother, Amica, and Kirk Rudy.
Products Make the Original distinguishable from the Counterfeit!
Packaging/Coding Thermal & Piezo Based Inkjet Inks - (regular + security aqueous pigment & dye, uv & IR fluo, and uv curable fluo)
- Ink Types.
Regular & Security; high resolution, high adhesion, highly abrasive, fully optimised, high speed printing ink formulations for porous and non-porous substrates, industrial grade thermal & piezoelectric print heads, inline/offline desktop printer & ink system manufacturers, as well as packaging/mailing applications:
(a) Regular: Aqueous dye/pigment mailing & coding inks (universal, smudge-resistant, up to 2-year shelf life, ultra-
fast & fast dry options. Fast dry for porous & uncoated paper-based substrates, and ultra-fast dry for synthetic
Teslin, treated non porous foils/blisters, etc. Fade, water, smudge resistant......and more>>)
(b) Security: Aqueous Invisible UV & IR, and UV curing UV fluorescent inks (fast-immediate dry, up to 2-year shelf life).
List of Services
List of Services
-
Our aqueous TIJ & Piezo - based industrial security UV & IR fluorescent products come in pigment & dye based
formulations specifically developed with good bonding/adhesion, fastness, and dry time for the packaging
industry. Both range of products print well on porous (uncoated paper/cardboard, uncoated corrugated
packaging [egg tray]), semi-porous substrates, synthetic (Teslin), and non-porous blister/coated foils.
-
Our high-purity UV/UV-LED curable specialty security pigment ink formulation is available for use in many piezo-
based systems and some thermal (TIJ 4.0) print engines/VDUs for the industrial, commercial, and graphic
printing markets. Options for marking/printing on sensitive packaging films (food, pharmaceutical,
cosmetics); as well as options for rigid or flexible materials (vinyl, polyester, PC, rigid PE, ID cards, data-cards,
mailing labels, envelopes, .....and more) >>.
List of Services
List of Services
List of Services
List of Services
- Invisible UV/NIR Inks Detection: from 365nm (UV) and 750nm - 1100nm (NIR), using black light (UV lamp) and filtered digital NIR camera/camcoder/IR scanner-reader (NIR-light) respectively. Both ink types provide high and superior covert security to products via the packaging materials and labels on which they are applied. For example, black/IR fluorescence ink will show high obsorbance at NIR range: clear in daylight, black under filtered camera.
- Brands: Inks based on advanced ink carriers, high performance dispersions, and zero defect design from manufacturers who supply OEMs.
- Availability: Currently in bulk containers (bottles, etc.) only.
(please enquire).
- Compatible Machines/Systems: high-speed, high-volume DoD industrial/commercial printers (standing or desktop), web/sheet-fed presses, VDUs, addressing/marking equipment, and ink delivery & modular printing systems: with single or multiple piezoelectric printheads by Canon, Ricoh, Brother, Amica, Fuji-Dimatix, Domino, Konica Minolta, Kyocera, Epson, Toshiba TEC; and with thermal (TIJ 4.0) printheads for HP monochrome & colour modules (M500, M800, C250, C500, C800) as well as Videojet, Kirk Rudy, Mark Andy 2200 series, Digital Design (Evolution, TIJ2.5).
Click on the button below for more information
Click here to enquire about our colours and inks not listed in the tables below.
Bulk Inks - For HP TIJ 2.5 & 4.0 - Printers
| Product Number | Product Description | Ink Colours | Price |
|---|---|---|---|
| AH-27BWRPP | Compatible HP 4500 regular dark black, high optical density, fast-dry, water-based pigment inkjet ink for HP TIJ 2.5 printers. Oustanding adhesion. Over 24min decap time enables intermittent printing and minimum maintenance. High resolution (600dpi) printing on uncoated surfaces. Applications: packaging/mail addressing . [Packing: 1 and 5 litre containers] | Black | TBQ |
| AH-28BWRPP | Compatible, high resolution up to 2400 dpi, HP TIJ4.0 4250 regular aqueous black pigment inkjet ink for DPI TIJ 425/850, TIJ 1275, TIJ 1700; iPAS 425/850, iPAS 425I; Webtron 650; Mark Andy MA2200 VDUs, etc [Packing: 1 and 5 litre containers] | Black | TBQ |
| AH-29XIVFSP | Invisible UV fluorescent Security solvent based fast-dry inkjet ink for HP TIJ 2.5 high speed industrial Printers and VDUs. Long decap time. Clear in daylight, and y/green fluorescence. [Packing: 1 litre bottle] | Yellowish Green Fluorescence | TBQ |
| Product Number | Product Description | Ink Colours | Price |
|---|---|---|---|
| AH-30XIVFCP | Invisible UV fluorescent UV curable Security inkjet ink with excellent colourfastness, superb adhesion, and resistance to UV degradation. Designed for HP TIJ 2.5 printers. Long decap time. [conventional UV bulb/UV-LED radiation drying] [Packing: 1 litre bottle] | Blue Fluorescence | TBQ |
| AH-31XIVFRP | Invisible Infra-Red (NIR) fluorescent Security inkjet ink designed for high-speed HP TIJ 2.5 printers. Highly absorbent at NIR range. Clear in daylight, Black under filtered camera [IR light detection] [Packing: 1 litre bottle]. | Black/IR Fluorescence, 840nm | TBQ |
| AH-32XIVFDP | Invisible UV fluorescent Security aqueous inkjet inks, optimised for HP TIJ 2.5 and TIJ4.0 printing systems/web presses. [HP M500, C500, C800,M800; HP IPAS 425i; iDataPrint H500; Webtron 650; Neopost AS-830; Digital Print TIJ 150; etc] [black light detection] Clear daylight. [Packing: 1 litre bottle per colour]. | Red, Green, and Blue fluorescence. | TBQ |
Cartridges Inks - For HP TIJ 2.5 & 4.0 - Printers
| Product Number | Product Description | Ink Colours | Price |
|---|---|---|---|
| AH-20BWRPP | 42ml, black regular aqueous pigment HP 45A ink cartridge for standalone & integrated style system | Black | TBQ |
| AH-21XIVFCPC | 42ml, Invisible UV fluorescent UV-curable HP 45A ink cartridge for standalone & integrated style systemS. Long decap time. [UV-Mercury Lamp/UV-LED] | Green Fluorescence | TBQ |
| AH-23XIVFRPC | 42ml, Invisible Infrared (IR) fluorescent Security Ink, optimised for high-speed HP TIJ 2.5 printers/systems. High absorbance at NIR range. Clear in daylight, black under filtered camera. [IR light detection] | Black/IR Fluorescence, 975nm | TBQ |
| Product Number | Product Description | Ink Colours | Price |
|---|---|---|---|
| AH-24XIVFDPC | 42ml, Invisible UV fluorescent Security aqueous inkjet Inks, optimised for high-speed HP TIJ 2.5 printers/systems. [Black/UV light detection]. Clear in daylight. Note: 'X' in the part number represents each ink colour. | Red, Yellowish Green, and Blue fluorescence. | TBQ |
| AH-25BVDPP | 775ml, sharp, high optical density, black, pigment ink cartridge for HP TIJ 4 based VDUs, labelling/addressing & mailing units/web presses [HP M500, C500, C800, M800, DJM IPAS 425i, Mark Andy 2200 series, HP IPAS 425i, iDataPrint H500/H800; Webtron 650, TIJ-850, etc. | Black | TBQ |
| AH-26BVDDP | 775ml, sharp, high optical density, black, dye ink cartridge for HP TIJ 4 based VDUs/addressing & mailing units/web presses. HP M500, M800, DJM IPAS 425i, Mark Andy 2200 series, HP IPAS 425i, iDataPrint H800/H500; Webtron 650, TIJ-850, etc. | Black | TBQ |
Discover & Explore!
Discover what you can do with our inks and explore the opportunities always revealed:
- Protect your brand and vast array of documents made from plastics and paper
- Add MICR (magnetic ink character recognition) to your document packaging & security. [Click here
to request quotation for our piezo-based high signal strength MICR inkjet inks (AH-33XIMBPS) - Add colour, variable text, and graphics flexibly at fast speed using high print resolution technologies
- Get more from your invisible QR codes. Add QR codes to your brand/documents using our inks, and embrace the benefits of the scannability & visibility of their images. Only non-QR code scanned invisible images are visible to the human eye, scanned invisible QR codes require the use of infrared light for visibility. This enhances the use of QR codes for a variety of anti-counterfeit applications across industries.
- Use our dye ink for high quality images, and pigment inks for lasting permanence whether you are just coding and marking with our regular inks or you are combining our UV secure with our IR secure inks to create a simple or complex hybrid of security features for your brand/documents
Videojet/Wolkes Ink Cartridges
| Product Number | Product Description | Ink Colours | Price |
|---|---|---|---|
| WLK660088 | 42ml, waterbased dye ink cartridge for semi-absorbent substrates. A quick drying ink with long-term decap time and very good resistance to light & UV. Produces ultra dark bar codes with well defined edges for scanning. Suitable for m600 basic & m600 Advanced printers. Packing: 10pcs/pack | Premium Black | TBQ |
| WLK667482 (UB7482) | 42ml, waterbased dye ink cartridge. Quick drying, UV resistant ink, with stable long decap time . Produces crisp bar codes on semi-absorbent substrates (uncoated & painted cardboard cartons, etc) used in the pharmaceutical, tobacco & food industries. Printers: m600 Advanced. Packing: 10pcs/pack | Universal Black | TBQ |
| Product Number | Product Description | Ink Colours | Price |
|---|---|---|---|
| WLK660072 | 42ml HP45A ink cartridge. Excellent light, water, wipe & rub resistance. No bleeding. Short drying times. No need for additional hot air drying. Prints on non-absorbent surfaces (lacquered cartons, cardboard boxes, blister foils and plastics) using Videojet m600 basic, m600 Advanced, m600 Touch, 8510. PACKING: X10pcs/pack | Black | TBQ |
| 16-21S | Fast drying, versatile HP TIJ 2.5 HP45A ink cartridge for Videojet 4320 and addressing/imaging inkjet systems used in mailing, commercial print & newspaper industries . Best for light coated stock, but may also be used in place of 16-29S on non-coated paper. PACKING: X10pcs/pack | Black | TBQ |
Digital Designs/Evolution Ink Cartridges
| Product Number | Product Description | Ink Colours | Price |
|---|---|---|---|
| 4500BK6 | 42ml, regular aqueous pigment ink cartridge for Eolution I/II/III printers and porous substrate & uncoated paper, PACKING: x6pcs/pack | Black | TBQ |
| 4500BL6 | 42ml, regular aqueous pigment ink cartridge for Eolution I/II/III printers and porous substrate & uncoated paper. PACKING: x6pcs/pack | Blue | TBQ |
| 4500CY6 | 42ml, regular aqueous pigment ink cartridge for Eolution I/II/III printers and porous substrate & uncoated paper. PACKING: x6pcs/pack | Cyan | TBQ |
| 4500GR6 | 42ml, regular aqueous pigment ink cartridge for Eolution I/II/III printers and porous substrate & uncoated paper. PACKING: x6pcs/pack | Green | TBQ |
| Product Number | Product Description | Ink Colours | Price |
|---|---|---|---|
| 4500YL6 | 42ml, regular aqueous pigment ink cartridge for Eolution I/II/III printers and porous substrate & uncoated paper. PACKING: x6pcs/pack | Yellow | TBQ |
| 4500RD6 | 42ml, regular aqueous pigment ink cartridge for Eolution I/II/III printers and porous substrate & uncoated paper. PACKING: x6pcs/pack | Red | TBQ |
| 4550BK6 | 42ml, regular aqueous pigment ink cartridge for Eolution I-LX/II-LX printers and porous substrate & uncoated paper. PACKING: x6pcs/pack | Black | TBQ |
| 4500UV6 | 42ml, Invisible UV Fluorescent aqueous pigment inkjet ink cartridge for Eolution I/II/III printers and porous substrate & uncoated paper. Packing: x6pcs/pack | Clear/Fluorescence | TBQ |
*** Light yellow (4500LTYW6) ) inks also available
Bulk Inks - For Epson Piezo Based Coders/Printers
| Product Number | Product Description | Ink Colours | Price |
|---|---|---|---|
| AE-30XRVCP | Regular pigmented UV curable (UV lamp/UV-LED), inkjet inks. Superb adhesion. High quality images. Durable Prints. Anti fade/UV degradation. For Epson DX4/DX5 printhead coders, roll-to-roll printers and flatbeds. Compatible materials PC, Teslin Synthetic, PVC card, PP, PE, PS, and Acrylic blister foils. 'X' in the product number represents the colours. PACKING/COLOUR: 5 litre/pack | Black, Magenta, Yellow, Cyan | TBQ |
| AE-31BRVCP | Invisible UV fluorecent UV curable (UV lamp/UV-LED) inkjet ink. For Epson DX4/DX5 printhead coders, roll-to-roll printers and flatbeds. Compatible materials PC, Teslin Synthetic, PVC card, PP, PE, PS, and Acrylic blister foils. For covert security features. PACKING : 1 litre/pack | Greenish Yellow | TBQ |
| AE-26XIVFP | Invisible UV fluorescent dye inkjet inks. Excellent adhesion. For Epson DX4/DX5 printhead coders, roll-to-roll printers and flatbeds. Compatible materials PC, Teslin Synthetic, PVC card, PP, PE, PS, and Acrylic blister foils. For covert security features. 'X' in the product number represents the colours [UV light detection]. Packing/Colour: 1litre bottle/pack | Red, Blue and Green fluorescence | TBQ |
Compatibility
- Epson DX4/DX5 print head coders, roll-to-roll printers, and flatbeds.
- Rigid materials - Polycarbonate, Teslin Synthetic, and
PVC cards
- Flexible roll media/films - Polypropylene (PP), Polyethylene (LDPE & LLDPE), Polystylene (PS), Acrylic blister foils
- 'NOTE. X' in our product numbers represent different colour options. Please state the colour that you are looking for when you request a quote or enquire.
